Core Board
M88
64-bit Industrial Core Board — RK3588 Flagship
Rockchip RK3588 4×A76 + 4×A55 @ 2.6 GHz
64-bit Industrial Core Board — RK3588 Flagship
| CPU | Quad-core Cortex-A76 @ 2.4 GHz + Quad-core Cortex-A55 @ 1.8 GHz |
| NPU | 6 TOPS @ INT8, RKNN accelerator |
| GPU | Mali-G610 MP4, OpenGL ES 3.2 / Vulkan 1.1 / OpenCL 2.2 |
| Memory | LPDDR4X up to 16 GB, 64-bit |
| Video | H.264/H.265/VP9/AV1 8K@60fps decode, 8K@30fps encode |
| Display | HDMI 2.1 + DP 1.4 + eDP + MIPI DSI, quad-display |
| Interface | PCIe 3.0 ×4 / USB 3.0 / SATA 3.0 / 2× GMAC |
| Wi-Fi 6 | Optional Wi-Fi 6 + BT 5 module |
| Operating | −40 ~ +85 °C industrial grade |
Industrial edge servers; Control room displays; AI inference boxes; Multi-camera NVR; Robotics
Quad-core Cortex-A76 @ 2.4 GHz + Quad-core Cortex-A55 @ 1.8 GHz
6 TOPS @ INT8, RKNN accelerator
LPDDR4X up to 16 GB, 64-bit
HDMI 2.1 + DP 1.4 + eDP + MIPI DSI, quad-display
−40 ~ +85 °C industrial grade
PCIe 3.0 ×4 / USB 3.0 / SATA 3.0 / 2× GMAC
Pricing is quoted per configuration and volume — there is no single list price. Send us the target quantity, configuration and destination and we will come back with a firm quote and lead time.
Yes. METO provides ODM and OEM customization on its platforms, including hardware configuration, enclosure, branding and packaging. See the ODM/OEM page for scope, or send us your requirements.
MOQ depends on whether you need a standard configuration or a customized build. It is confirmed together with the quotation — tell us your target volume and we will state the MOQ for that configuration.
