Core Board
M68
64-bit Commercial-grade Core Board — Quad A55 with NPU
Rockchip RK3568 Quad-core Cortex-A55 @ 2.0 GHz
64-bit Commercial-grade Core Board — Quad A55 with NPU
| CPU | Quad-core 64-bit ARM Cortex-A55 @ up to 2.0 GHz, 22 nm |
| NPU | 0.8 TOPS @ INT8, RKNN accelerator |
| GPU | Mali-G52 2EE |
| Memory | DDR4 / LPDDR4 up to 8 GB |
| Video | H.264/H.265 4K@60fps decode, 1080P@60fps encode |
| Display | HDMI 2.0 + eDP + MIPI DSI + RGB, dual-display |
| Interface | PCIe 3.0 / USB 3.0 / SATA 3.0 / GMAC / SDIO 3.0 |
| Package | Stamp-hole, compact size |
| Operating | 0 ~ +70 °C commercial grade |
